400kvar Customized Color High Voltage Distribution 110v - 690v Cabinet Capacitor Cabinet
| Place of Origin | Chengdu, China |
|---|---|
| Brand Name | Customized |
| Certification | CE, ISO,CCC |
| Model Number | capacitor bank |
| Minimum Order Quantity | 1 unit |
| Price | Pending |
| Packaging Details | Wooden Case |
| Delivery Time | 30work days |
| Payment Terms | T/T,D/A |
| Supply Ability | 1000PCS/YEAR |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Features | Long Service Life | OEM | Offered |
|---|---|---|---|
| Color | Customized | Size | Customized |
| Rated Current | Customized | Color | Custom |
| Size | Custom | Feature | High Precision |
| Advantage | High Safety | Product Name | High Voltage Distribution Cabinet |
| Highlight | 400kvar High Voltage Distribution Cabinet,customized color High Voltage 110v Distribution Cabinet,690v capacitor cabinet |
||
Product Description
400kvar Capacitor Bank Cabinet with Harmonic Filter Reactor
Key attributes
Other attributes
Place of Origin
chengdu China
Brand Name
JHL
Model Number
capacitor bank
Rated Voltage
110v-690v
Rated Frequency
50Hz/60Hz
Switching mode
compound switch
Compensation capacity
150kvar 200kvar 300kvar 400Kvar
Certificate
CCCCE
Altitude
2200m
Product Name
static var compensator
Type
static kvar compensator capacitor banks
Application
Power factor correction
Packaging and delivery
Packaging Details
dwooden case
Specification of APFC Panel:
- Rated Voltage: 380/ 400/ 415/ 440/ 690
- Rated Frequency: 50/ 60 Hz
- Rated Out Put: 20-5000 KVAr
- Configuration: Delta/ Star floating/ Star grounding
- Number of steps: 1-30.
- Step Distribution: Equal/ Binary/ Unequal
- Series Reactor: 5%, 5.5%, 5.67%, 6%,7%,8%,12.5%14%
- Reactor: Optional
- Switching device: Thyristor/ Capacitor duty contactor/compond switch
- Panel Type: Standard/ Modular/ Customized
- Capacitors: Resin filled/ Gas filled/ APP
- Protections: OV/ UV/ SC/ EF/ OT
- Measuring CT: 1 or 3
Specifications
The Panels are Contactor switched compound switched or Thyristor switched type static VAR compensator,it is a set of electrical devices for providing fast-acting reactive power compensation in real time on electricity transmission networks. with the high performance for regulating voltage, power factor, harmonics and stabilizing the system.
Sichuan Jinhuili Electric Co., Ltd. is specialized in distribution automation, power quality, energy efficiency management of the main products and services; The products include high and low voltage power distribution equipment, uninterruptible UPS power supply, emergency power supply, DC power supply, complete sets of intelligent control equipment, solar photovoltaic power generation, energy storage management, operation and maintenance and other comprehensive automation.
